RP1253 Asphalt Concrete Paver
Item | Unit | Patameter | Remark | |
1 | Basic Working Width | m | 2.5 |
|
2 | Max Working Width | m | 12 |
|
3 | Max Working Thickness | mm | 350 |
|
4 | Paving Speed | m/min | 0～18 |
|
5 | Traveling Speed | km/h | 0～3.0 | China Ⅱ |
Theoretic Productivity | 0～3.5 | China Ⅲ | ||
6 | Hopper Capacity | t/h | 900 |
|
7 | Gradient Ability | t | 15 |
|
8 | Smoothness | ％ | 20 |
|
9 | Smoothness | mm | 0.8 |
|
10 | Arciform Range | % | -1～+4 |
|
11 | Engine Type | -- | BF6M1013 | China Ⅱ |
BF6M1013 | China Ⅲ | |||
12 | Rated Power | kW | 183 | China Ⅱ |
191 | China Ⅲ | |||
13 | Rated Revolution | r/min | 2000 |
|
14 | Conveyancer capacity | m/min | 0～22 |
|
15 | Auger revolving speed | r/min | 0～90 |
|
16 | Tamper Revolution | r/min | 0～1400 |
|
17 | Tamper Amplitude | mm | Main 5/Ancillary 0、5、10 |
|
18 | Tamper Vibration Frequency | Hz | 0～42 |
|
19 | Overall Dimensions | mm | 6760×2600×3950 |
|
20 | Gross Weight | t | 23.5～32 |
|
21 | Fuel tank capacity | L | 300 |
|
22 | Hydraulic capacity | L | 300 |
|
23 | Screed heating method | / | Gas heating |
|
24 | Material level control mode | / | Automatic control by ultrasonic sensor |
|
25 | Mode of vibration | / | Eccentric vibration |
|
26 | Automatic leveling control | / | MOBA Digital Angle leveling instrument |
|
